Q02PHCPU Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC

The Mitsubishi Q02PHCPU is a high-performance programmable logic controller (PLC) CPU module from the MELSEC Q Series, specifically designed for motion control applications. It functions as the central processing unit for sophisticated multi-axis positioning systems, seamlessly integrating sequence control, motion control, and information processing within a single, compact unit. The Q02PHCPU is ideal for complex machinery requiring precise synchronization, such as packaging machines, assembly robots, and CNC equipment, offering a powerful and streamlined solution for advanced automation challenges.

• Unified Control Platform: Combines sequence logic control and up to 4 axes of servo motion control in one CPU, simplifying system architecture and programming.
• High-Speed Processing: Features a powerful 200 MHz processor, enabling fast scan times for complex logic and high-speed, precise motion instructions.
• Synchronous Control: Advanced synchronous control functions ensure perfect coordination between multiple axes, crucial for applications like electronic gearing and cam profiling.
• Dedicated Motion Instructions: Supports a comprehensive set of motion control commands (e.g., linear interpolation, circular interpolation) for sophisticated trajectory planning.
• Large Program Capacity: Offers a substantial 60 KB program capacity and 192 KB of device memory to handle large and intricate control programs.
• Seamless Integration: Easily connects with MELSECNET/H networks and other Mitsubishi servo amplifiers (like the MR-J4 series) for a fully integrated factory automation system.
• Robust Design: Built to withstand harsh industrial environments with high noise immunity and reliable operation.

• Material: The module is constructed with a robust metal (typically aluminum alloy) casing for heat dissipation and durability, with a high-quality plastic front panel. The internal circuitry uses industrial-grade electronic components.
• Primary Uses:
  • Multi-axis precision positioning systems
  • Semiconductor manufacturing equipment
  • Packaging and labeling machinery
  • Robotic arm control and assembly lines
  • Textile machinery and printing presses
  • Any application requiring synchronized motion and sequential logic.
