Rosemount 3051 Pressure Transmitter 3051L2AA2AD21AADFE5 0-5516KPA

Name: Rosemount 3051 Pressure Transmitter 3051L2AA2AD21AADFE5 0-5516KPA
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 3051L2AA2AD21AADFE5
Price: 210.00 USD
Availability: InStock

Nom De Marque:	Rosemount
Numéro De Modèle:	3051L2AA2AD21AADFE5
Quantité De Produit:	1

Informations détaillées

Description du produit

Informations détaillées

Place of Origin:

USA

Brand: Rosemount Model: 3051L2AA2AD21AADFE5 Origin Of Country:

Singapore

Type:

Pressure Transmitter

Range:

0-5516KPA

Communication Protocol:

4-20 MA HART

Packaging Details:

New Original Box

Description du produit

Rosemount 3051 Pressure Transmitter 3051L2AA2AD21AADFE5 0-5516KPA

With the Rosemount 3051 Pressure Transmitter, you’ll gain more control over your plant. You’ll be able to
reduce product variation and complexity as well as your total cost of ownership by leveraging one device
across a number of pressure, level and flow applications. You’ll have access to information you can use to
diagnose, correct and even prevent issues. And with unparalleled reliability and experience, the Rosemount
3051 is the industry standard that will help you perform at higher levels of efficiency and safety so you can
remain globally competitive.

Rosemount™ 3051L Level Transmitter

With field-proven reliability, the Rosemount 3051L Level Transmitter is a fully-integrated level solution. This safety-certified transmitter allows for direct mounting or a Tuned-System™ assembly for optimized performance that reduces temperature effects by 10-20% and improves response time by over 80% versus traditional installations. Power advisory diagnostics enable this device to monitor electrical loop integrity and the Local Operator Interface (LOI) offers on-site commissioning.

Ordering Type

3051L Wireless / Level Transmitter

Rosemount 3051L Level Transmitter Ordering Information

The Standard offering represents the most common options. The starred options should be selected for best delivery.
The Expanded offering is subject to additional delivery lead time.

Specifications:

Rangedown	Up to 150:1
Communication Protocol	4-20 mA HART, WirelessHART®, FOUNDATION fieldbus, Profibus, 1-5 V Low Power HART
Measurement Range	Up to 2000psi (137,89 bar) Differential, Up to 2000psig (137,89 bar) Gage, Up to 4000psia (275,79 bar) Absolute
Process Wetted Material	316L SST, Alloy C-276, Alloy 400, Tantalum, Gold-plated Alloy 400, Gold-plated 316L SST
Diagnostics	Basic Diagnostics, Power Advisory Diagnostics
Certifications/Approval	SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE, hazardous location, see full specs for complete list of certifications

Certifications:

1. Certificate of Origin

2. Calibration Certificate

3. Material Traceability Certification

Typical model number: 3051L 2 A A0 D 21 A A F1

We also can offer these modeles:

Brand	Model	Condition
Rosemount	3051CD0A02A1AB1H2L4M5	New
Rosemount	3051CD1A02A1AB1H2L4M5	New
Rosemount	3051CD2A02A1AB1H2L4M5	New
Rosemount	3051CD3A02A1AB1H2L4M5	New
Rosemount	3051CD4A02A1AB1H2L4M5	New
Rosemount	3051CD5A02A1AB1H2L4M5	New
Rosemount	3051TG1A2B21A	New
Rosemount	3051TG3A2B21AB4	New
Rosemount	3051TG1A2B21AB4M5K5	New
Rosemount	3051TG5A2B21AB4M5E5	New
Rosemount	3051TG5A2C21AB4M5K5	New
Rosemount	3051TA1A2B21AB4M5K5	New
Rosemount	3051TA3A2B21AB4M5E5	New
Rosemount	3051TA3A2B21AB4M5I5	New

Rosemount	3051GP1A2B21AB4M5	New
Rosemount	3051GP3A2B21AB4M5K5	New
Rosemount	3051GP4A2B21AB4M5E5	New
Rosemount	3051GP5A2B21AB4M5I5	New
Rosemount	3051CG1A02A1AB1H2L4M5
Rosemount	3051CG1A02A1AB3H2L4M5
Rosemount	3051CG4A02A1AB1H2L4M5K5	New
Rosemount	3051CG4A02A1AB1H2L4M5I5	New
Rosemount	3051CG5A02A1AB3H2L4M5I5	New
Rosemount	3051CA1A02A1AB1H2L4M5	New
Rosemount	3051CA2A02A1AB1H2L4M5K5	New
Rosemount	3051CA4A02A1AB1H2L4M5E5	New
Rosemount	3051CA5A02A1AB1H2L4M5I5	New
Rosemount	3051CA3A02A1AB3H2L4M5K5	New
Rosemount	3051CA5A02A1AB3H2L4M5K5	New
Rosemount	3051CA1A02A1AB3H2L4M5E5	New

Rosemount 3051 Pressure Transmitter 3051L2AA2AD21AADFE5 0-5516KPA 0
